Model |
Arm form Type |
Suitable I.M.M ton |
Vertical mm |
Crosswise mm |
Traverse mm |
Posture |
Max Load KG |
Minimun Take out sec |
Drive Way Z.Y.X |
Air Pressure |
Air Usage nl |
Power |
Net Weight kg |
| SVBI-1200S | Single Cut | 300-550 | 1200 | 950 | 1870 | 90° | 10KG | 2.4 |
X.Y.Z AC Servo Motor |
0.5Mpa | 1.2 | AC220V | 450 |
| SVBI-1200D | S:700 D:700 | ||||||||||||
| SVBI-1400S | 500-800 | 1400 | 950 | 2170 | 2.5 | 480 | |||||||
| SVBI-1400D | S:700 D:700 |
| Model | A | B | C | D | E | F | G | H | 1 | J | K | L | M | N | O | P | Q |
| SVBI-1200S | 2032 | 2537 | 1870 | 254 | 439 | 1200 | 193 | 374 | 1446 | 536 | 1119 | 978 | 141 | - | |||
| SVBI-1200D | 226 | 806 | 313 | 146 | 806 | 167 | |||||||||||
| SVBI-1400S | 2272 | 2837 | 2170 | 1400 | - | 978 | 141 | - | - | - | |||||||
| SVBI-1400D | 226 | 806 | 313 | 146 | 806 | 167 |
By reason of improved,specifications and appearance change,no further notice,please understanding
